• GPU technology by NVIDIA GT 745M
• Multi Displays
• 642 GFLOPS
• 384 CUDA cores
• 2048 MB memory
• 1 x PCI-E[x4] to P2 wafer
• Lower power consumption 35Watt
Specification:
| Form Factor | VPX 3U EURO CARD(160×100 mm) | |
| Graphic Processor Unit | GPU | NVIDIA GT745M |
| Architecture | KEPLER | |
| GPU name | GK107 | |
| Transistors (Millions) | 1270 | |
| Memory | Technology | GDDR5 |
| Capacity | 2GB | |
| Memory Bandwidth (GB/sec) | 28.8 | |
| Memory Clock (MHz) | 900 | |
| Memory Interface Width (bit) | 128 | |
| Interface | VGA | 1 |
| Display port | 2 | |
| PCI-E link-width | 1 x PCI-E[x8], GEN3 from VPX P1 wafer and 1 x PCI-E[x4] to VPX P2 wafer | |
| I2C | 1 | |
| Support | OPCL | 4.5 |
| OPGL | 1.1 | |
| Shader Model | 5 | |
| Direx | 11 | |
| Ruggedization | Operation Temp | -40° to +85°C |
| Shock | 40g, 11ms for 3axes | |
| Vibration | 0.2g²/Hz @ 5-2000Hz vibration | |
| Humidity | 0 ~ 80% | |
| PCB finished | IPC 6012 Class-3 and conformal coating |
